Geotextile

PRODUCT VIDEO
PRODUCT DESCRIPTION

Geotextile is usually made from a synthetic polymer such as polypropylene (PP), polyester (PET) etc. raw material and processed by woven & needle punched non woven or heat bonded methods. It is used as protection, filtration or separation layer alternative to diverse terrain such as soil, rock, sand and so on, also the UV Resistance and Thermal Bonded etc. performance is available.

As the professional geotextile fabric manufacturer and supplier in China, we could produce non woven geotextile fabric including: polyester (PET) staple fiber geotextile, polypropylene (PP) staple fiber geotextile, polyester (PET) continuous filament geotextile, polypropylene (PP) continuous filament geotextile.

Woven geotextile including: Flat yarn geotextile, Split yard geotextile, Filament woven geotextile, Weed mat.

The functions are including: filtration, reinforcement, drainage, separation, protection and stabilisation etc.

Gram
weight
Thicknes
s(mm)
Breaking
strength(kn/m
)
CBR burst
strength(K
N)
Elongation
at
break(%)
Tear Strength
(KN)
Sieve size
099(035)mm
100 0.9 2.5 0.3 25-1000.08 0.07-2.0
150 1.3 4.5 0.6 25-1000.12 0.07-2.0
200 1.7 6.5 0.9 25-1000.16 0.07-2.0
250 2.1 8.0 1.2 25-1000.20 0.07-2.0
300 2.4 9.5 1.5 25-1000.24 0.07-2.0
350 2.7 11.0 1.8 25-1000.28 0.07-2.0
400 3.0 12.5 2.1 25-1000.33 0.07-2.0
450 3.3 14.0 2.4 25-1000.38 0.07-2.0
500 3.6 16.0 2.7 25-1000.42 0.07-2.0
600 4.1 19.0 3.2 25-1000.46 0.07-2.0
800 5.0 25.0 4.0 25-1000.60 0.07-2.0
Filament Fiber Needle Punched Nonwoven Geotextile
  Weight  100g  150g200g250g300g400g500g600g800g
  Weight Variation(%)  -6   -6   -6   -5 -5   -5   -4   -4   -4
  Thickness(mm)  0.8   1.2 1.6 1.9 2.2 2.8 3.4 4.2 5.5
  Width Variation(%) 0.5
  Breaking Strength (MD and TD)(KN/m)  4.5   7.5 10.0 12.5 15 20.5 25.0 30.0 40.0
  Elongation at Break (MD and TD)(%)40~80
  CBR Mullen Burst Strength(KN)  0.8   1.4 1.8 2.2 2.6 3.5 4.7 5.5 7.0
  Sieve Size O90(mm) 0.07~0.2
  Vertical Permeability Coefficient (cm/s)K*(10-1-10-3)(K=1.0~9.9)
  Tear Strength (MD and TD)(KN)  0.14   0.21 0.28 0.35 0.42 0.56 0.70 0.82 1.10


FACTORIES AND WAREHOUSES

Products and warehouse.jpg


PACKAGING AND DELIVERY

Packaging and delivery.jpg


QUALIFICATIONS AND CERTIFICATES
FAQ

QDo you accept the small order?
A
Sure. We accept small order if your order quantity is less than MOQ, we will do our best to help you expand your market.


QShould we pay for the sample cost?
A
It will depend on the quantity of the samples. Generally the sample fees will be refunded in bulk order.



Q:How long can I expect to get the samples?
A:The samples will be ready for delivery in 2-5 days. The samples will be sent to you via express and arrive in 3-5 days.
